full pruduction line of ELECTRIC HOIST

Weyou Technology Company has the full pruduction line of ELECTRIC HOIST:

• electric wire rope hoist with motorized trolley,
• low headroom electric hoist,
• explosion-proof electric hoist,
• portable electric hoist,
• double girder electric hoist,
• dual-speed electric hoist,
• dual-voltage electric hoist.
• ...

Get more information at www.weyou.co or email at sales@weyou.co

GCL/GCT-A Manual Beam Trolley

GCL/GCT-A  Manual Beam Trolley Anti-Drop Series:

GCL-A Geared Trolley ; Pull Trolley, Travel Trolley
GCT-A Plain Trolley, Push Trolley, Beam Trolley

Following are the features of Anti-Drop Manual Trolley:
1) With fine adjustment and fittings to the beam, easily adjusted by the round nuts
2) Easily adjustable (round nuts) to fit a wide range of beam widths
3) Adjustable to fit a wide range of beam profiles
4) Excellent rolling features due to machined steel wheels mounted on pre-lubricated encapsulated ball bearings
5) Standard anti-tilt and anti-drop devices

GCL-A Geared Trolley ;

GCT-A Plain Trolley,

Why KOIO Electric chain hoist sell so well all over the word

Why KOIO Electric chain hoist sell so well all over the word, which has following features say it;

 Features of KOIO Electric Chain Hoist:

    Shell: High tensile alloy steel,  Sealed design, Excellent heat eliminate, which make it excellent suitable in poor operating conditions.

     Reverse phase protection device: which can cut down the work to protect safety of operator, if wiring incorrect connection.

     Limit switch: Both lifting and dropping are protected with limit switches, to prevent to exceed limits.

     Control voltage: 24V, 36V, 48V, low voltage, safety control.

Super Quality CD1 Electric Wire Rope Hoist

Super Quality CD1 Electric Wire Rope Hoist

Motor: Hoist Motor is an taper type rotor motor with braking,it is made by Nanjing special motor factory,it is of the best quality motors, it has bigger torque, so it can be adapted to moving frequently,the Maximum torque is 2.4-3 times than the rated torque.

Gear Box: Hoist Gear Box has specially treated gears for high wear resistance. Each Geared Shaft assembly is supported on ball or roller bearings , to ensure smooth, low-friction operation.

Wire Rope: Hoisting rope comply with the exporting standards. The leading rope taken by the Drum, does not slip sideways when slack. The factor of safety, on the nominal breaking strength of the rope is six.

Rope Drum: Grooved Drum, seamless pipe of adequate length to be wounded in one layer and to provide proper support for the rope to minimize abrasive wear is provided. Drum Shaft resolves on Ball Bearings for ensuring smooth running.

Electric apparatus controlling system: Model CD₁ and MD₁ is composed of the contactor box,controlling switch,cut-off limiter.the working voltage of controlling switch is 380V,36V or 24V(safety voltage).

Rope Guide: Rope Guide is in two halves, ensuring easy accessibility. It encircles the Drum completely so that the rope may not uncoil even when the Hoist is in unloaded condition. The rope guides of our company is thicken and dilated, so that it is not easy to be damaged.

Hook: The Hook Block is tested to 150 % of full load before assembly. The rope sheaves are fully guarded with protective steel casting . All sheaves rotate on ball bearing.The pulley is thicken and dilated than domestic common pulley.

LCD1 Low Headroom Wire Rope Electric Hoist

LCD1 LMD1 Low headroom wire rope hoist is a new generation of electric hoist, which structure design is exquisite, superior performance, novelty and good-looking appearance.

It is improved from CD1 & MD1 type electric hosit, the working condition same as CD1 & MD1 type wire rope electric hoist, while it increases more lifting headroom and save the construction space of workshop（200-500mm）. Especially for the plant with height restriction, it is your perfect choice.

LCD1 Single Speed Low Head Room Wire Rope Electric Hoist

LMD1 Daul Speed Low Head Room Wire Rope Electric Hoist

7.5T KOIO Electric Chain Hoist Parameters

7.5 Ton KOIO Electric Chain Hoist

1. Features of KOIO Electric Chain Hoist:
    Shell: High tensile alloy steel,  Sealed design, Excellent heat eliminate, which make it excellent suitable in poor operating conditions.
    Reverse phase protection device: which can cut down the work to protect safety of operator, if wiring incorrect connection.
    Limit switch: Both lifting and dropping are protected with limit switches, to prevent to exceed limits.
    Control voltage: 24V, 36V, 48V, low voltage, safety control.

2. Specification of KOIO Electric Chain Hoist:
    Lifting Capacity: 7.5 Ton
    Lifting Speed: 1.8/0.6 m/min
    Insulation Grade: F
    Travelling Speed: 11 m/min (low), 21 m/min (high)
    Work Voltage: 220V-600V Daul voltage available
    Control Voltage: 24V/36V/48V
    No. of Load Chain: 3
    Chain Size: 11.2mm
    I-Beam: 125-178 mm

3. Photos of KOIO Electric Chain Hoist:


a. KOIO Electric Chain Hoist with Motorized Trolley  (Capacity 7.5 Ton)

b. KOIO Electric Chain Hoist with Hook Suspension (Capacity 7.5 Ton)

c. KOIO Electric Chain Hoist with Low Headroom (Capacity 7.5 Ton)

introduction of KOIO electric chain hoist

KOIO Electric Chain Hoist here in Weyou Technology Company can be devided into four types:
1> KOIO Electric Chain Hoist with Hook Suspension

2> KOIO Electric Chain Hoist with Geared/Plain Trolley

3> KOIO Electric Chain Hoist with Moterized Trolley

4> KOIO Electric Chain Hoist with Low Headroom
